工业用柴油发电机组
上柴系列 12-2500KVA
上柴动力隶属中国最大汽车集团——上汽集团，并与三菱合资生产菱重系列大功率发动机。产品以高可靠性和强劲性能闻名，适用于矿山、租赁、通信及建筑领域，并拥有出色的高原适应能力。
优能上柴系列发电机组功率覆盖12kVA至2200kVA，具备强瞬态响应能力和低温启动能力，并支持50Hz/60Hz频率切换。
| 机组型号 | 主用功率 | 备用功率 | 发动机 | 电机 | 外形尺寸(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | 型号 | 调速方式 | 型号 | 静音型 | ||
| 单相 | |||||||||
| YDSD13E/S-E/S/SS | 12 | 12 | 13 | 13 | 4Z2.3-G11 | M | Y164D/1P | 1800*800*1150 |  YDSD13E&S-E&S&&SS Technical Data.pdf |
| YDSD18E/S-E/S/SS | 16 | 16 | 18 | 18 | 4Z2.7-G11 | M | Y184ED/1P | 1920*850*1150 | YDSD18E&S-E&S&&SS Technical Data.pdf |
| YDSD22E/S-E/S/SS | 20 | 20 | 22 | 22 | 4Z3.0-G11 | M | Y184EF/1P | 2058*880*1150 | YDSD22E&S-E&S&&SS Technical Data.pdf |
| YDSD28E/S-E/S/SS | 25 | 25 | 28 | 28 | 4Z3.2-G11 | M | Y184G/1P | 2218*880*1150 | YDSD28E&S-E&S&&SS Technical Data.pdf |
| 三相 | |||||||||
| YDSD17E3/S3-E/S3/SS3 | 15 | 12 | 16 | 13 | 4Z2.3-G11 | M | Y164D | 1800*800*1150 | YDSD17E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD23E3/S3-E/S3/SS3 | 20 | 16 | 23 | 18 | 4Z2.7-G11 | M | Y184ED | 1920*850*1150 | YDSD23E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD28E3/S3-E/S3/SS3 | 25 | 20 | 28 | 22 | 4Z3.0-G11 | M | Y184EF | 2058*880*1150 | YDSD28E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD34E3/S3-E/S3/SS3 | 31 | 25 | 34 | 28 | 4Z3.2-G11 | M | Y184G | 2218*880*1150 | YDSD34E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD44E3/S3-E/S3/SS3 | 40 | 32 | 44 | 35 | 4ZT3.2-G11 | M | Y184J | 2218*880*1150 | YDSD44E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD55E3/S3-E/S3/SS3 | 50 | 40 | 55 | 44 | 4ZT3.5-G21 | E | Y224D | 2520*1000*1250 | YDSD55E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD70E3/S3-E/S3/SS3 | 63 | 50 | 69 | 55 | 4ZT4.1-G21 | E | Y224E | 2520*1000*1250 | YDSD70E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD75E3/S3-E/S3/SS3 | 68 | 55 | 75 | 60 | 4ZTAA4.1-G21 | E | Y224F | 2520*1000*1250 | YDSD75E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD88E3/S3-E/S3/SS3 | 75 | 60 | 83 | 66 | 4ZTAA4.1-G22 | E | Y224G | 2520*1000*1250 | YDSD88E3&S3-E&S3&&SS3 Technical Data.pdf |
| YDSD110E3/S3 | 100 | 80 | 110 | 88 | SC4H140D2 | E | Y274C | 2660*1100*1520 | YDSD110E3&S3. Technical Data.pdf |
| YDSD125E3/S3 | 113 | 90 | 125 | 100 | SC4H160D2 | E | Y274D | 2660*1100*1520 | YDSD125E3&S3. Technical Data.pdf |
| YDSD138E3/S3 | 125 | 100 | 138 | 110 | SC4H180D2 | E | Y274DS | 2660*1100*1520 | YDSD138E3&S3. Technical Data.pdf |
| YDSD150E3/S3 | 137 | 110 | 150 | 120 | 6HTAA6.5-G21 | E | Y274E | 3150*1100*1750 | YDSD150E3&S3. Technical Data.pdf |
| YDSD165E3/S3 | 150 | 120 | 165 | 132 | SC7H205D2 | E | Y274FS | 3150*1100*1750 | YDSD165E3&S3. Technical Data.pdf |
| YDSD175E3/S3 | 163 | 130 | 175 | 140 | SC7H220D2 | E | Y274G | 3250*1100*1750 | YDSD175E3&S3. Technical Data.pdf |
| YDSD206E3/S3 | 188 | 150 | 206 | 165 | SC7H250D2 | E | Y274G | 3250*1100*1750 | YDSD206E3&S3. Technical Data.pdf |
| YDSD220E3/S3 | 200 | 160 | 220 | 180 | SC8D280D2 | E | Y274H | 3650*1280*1950 | YDSD220E3&S3. Technical Data.pdf |
| YDSD250E3/S3 | 225 | 180 | 250 | 200 | SC9D310D2 | E | Y274J | 3650*1280*1950 | YDSD250E3&S3. Technical Data.pdf |
| YDSD275E3/S3 | 250 | 200 | 275 | 220 | SC9D340D2 | E | Y274K | 3650*1280*1950 | YDSD275E3&S3. Technical Data.pdf |
| YDSD313E3/S3 | 275 | 220 | 313 | 250 | SC10E380D2 | E | Y4D | 4110*1500*2200 | YDSD313E3&S3. Technical Data.pdf |
| YDSD350E3/S3 | 313 | 250 | 350 | 280 | SC10E420D2 | E | Y4ES | 4210*1500*2200 | YDSD350E3&S3. Technical Data.pdf |
| YDSD375E3/S3 | 344 | 275 | 375 | 300 | SC10E460D2 | E | Y4FS | 4210*1500*2200 | YDSD375E3&S3. Technical Data.pdf |
| YDSD400E3/S3 | 362 | 290 | 400 | 320 | SC10E480D2 | E | Y4F | 4310*1700*2200 | YDSD400E3&S3. Technical Data.pdf |
| YDSD413E3/S3 | 375 | 300 | 413 | 330 | SC13E500D2 | E | Y4F | 4310*1700*2200 | YDSD413E3&S3. Technical Data.pdf |
| YDSD440E3/S3 | 400 | 320 | 437 | 350 | SC13E550D2 | E | Y4FG | 4310*1700*2200 | YDSD440E3&S3. Technical Data.pdf |
| YDSD500E3/S3 | 450 | 360 | 500 | 400 | 6ETAA12.8-G31 | CR | Y5C | 4310*1700*2200 | YDSD500E3&S3. Technical Data.pdf |
| YDSD550E3/S3 | 500 | 400 | 550 | 440 | 6ETAA12.8-G310 | CR | Y5D | 4310*1700*2200 | YDSD550E3&S3. Technical Data.pdf |
| YDSD625E3/S3 | 563 | 450 | 625 | 500 | SC25K778D2 | E | Y5ES | 5550*1950*2500 | YDSD625E3&S3. Technical Data.pdf |
| YDSD688E3/S3 | 625 | 500 | 688 | 550 | SC25K855D2 | E | Y5FS | 5550*1950*2500 | YDSD688E3&S3. Technical Data.pdf |
| YDSD750E3/S3 | 700 | 560 | 750 | 600 | SC25K930D2 | E | Y6B | 5700*2050*2540 | YDSD750E3&S3. Technical Data.pdf |
| YDSD825E3/S3 | 750 | 600 | 825 | 660 | SC25K990D2 | E | Y6B | 5700*2050*2540 | YDSD825E3&S3. Technical Data.pdf |
| YDSD900E3/S3 | 825 | 660 | 900 | 720 | 6KTAA25-G31 | CR | Y6B | 5700*2050*2540 | |
| YDSD1000E3/S3 | 900 | 720 | 1000 | 800 | 6KTAA25-G320 | CR | Y6D | 5900*2250*2550 | YDSD1000E3&S3. Technical Data.pdf |
| YDSD1100E3/S3 | 1000 | 800 | 1100 | 880 | 6KTAA25-G321 | CR | Y6E | 5900*2250*2550 | YDSD1100E3&S3. Technical Data.pdf |
| YDSD1688E3/S3 | 1563 | 1250 | 1687.5 | 1350 | 12KTA58-G35 | CR | LSA50.2 VL10 | ISO 40'ft HQ | YDSD1688E3&S3. Technical Data.pdf |
| YDSD1875E3/S3 | 1688 | 1350 | 1875 | 1500 | 12KTA58-G34 | CR | LSA52.3 S5 | ISO 40'ft HQ | YDSD1875E3&S3. Technical Data.pdf |
| YDSD2063E3/S3 | 1875 | 1500 | 2062.5 | 1650 | 12KTA58-G33 | CR | LSA52.3 S6 | ISO 40'ft HQ | YDSD2063E3&S3. Technical Data.pdf |
| YDSD2250E3/S3 | 2000 | 1600 | 2250 | 1800 | 12KTA58-G32 | CR | LSA52.3 S6 | ISO 40'ft HQ | YDSD2250E3&S3. Technical Data.pdf |
| YDSD2500E3/S3 | 2250 | 1800 | 2500 | 2000 | 12KTA58-G31 | CR | LSA52.3 L9 | ISO 40'ft HQ | YDSD2500E3&S3. Technical Data.pdf |
| 型号 | 主用功率 | 备用功率 | 发动机 | 电机 | 外形尺寸(LxWxH)(MM) | ||||
| kVA | kW | kVA | kW | 型号 | 调速方式 | 型号 | 静音型 | ||
| 单相 | |||||||||
| YDSD19E/S/SS | 16 | 16 | 18 | 18 | 4Z2.3-G12 | M | Y164D/1P | 1800*800*1150 | YDSD19E&S&SS Technical Data.pdf |
| YDSD23E/S/SS | 20 | 20 | 22 | 22 | 4Z2.7-G12 | M | Y184E/1P | 1920*850*1150 | YDSD23E&S&SS Technical Data.pdf |
| YDSD26E/S/SS | 24 | 24 | 26 | 26 | 4Z3.0-G12 | M | Y184EF/1P | 2058*880*1150 | YDSD26E&S&SS Technical Data.pdf |
| 三相 | |||||||||
| YDSD24E3/S3/SS3 | 20 | 16 | 23 | 18 | 4Z2.3-G12 | M | Y164D | 1800*800*1150 | YDSD24E3&S3&SS3 Technical Data.pdf |
| YDSD29E3/S3/SS3 | 25 | 20 | 28 | 22 | 4Z2.7-G12 | M | Y184ED | 1920*850*1150 | YDSD29E3&S3&SS3 Technical Data.pdf |
| YDSD33E3/S3/SS3 | 30 | 24 | 33 | 26 | 4Z3.0-G12 | M | Y184EF | 2058*880*1150 | YDSD33E3&S3&SS3 Technical Data.pdf |
| YDSD45E3/S3/SS3 | 40 | 32 | 44 | 35 | 4Z3.2-G12 | M | Y184H | 2218*880*1150 | YDSD45E3&S3&SS3 Technical Data.pdf |
| YDSD48E3/S3/SS3 | 44 | 35 | 48 | 39 | 4ZT3.2-G12 | M | Y184H | 2218*880*1150 | YDSD48E3&S3&SS3 Technical Data.pdf |
| YDSD70E3/S3/SS3 | 63 | 50 | 70 | 56 | 4ZT3.5-G21 | E | Y224D | 2520*1000*1250 | YDSD70E3&S3&SS3 Technical Data.pdf |
| YDSD83E3/S3/SS3 | 75 | 60 | 83 | 66 | 4ZT4.1-G21 | E | Y224E | 2520*1000*1250 | YDSD83E3&S3&SS3 Technical Data.pdf |
| YDSD88E3/S3/SS3 | 80 | 64 | 88 | 70 | 4ZTAA4.1-G21 | E | Y224F | 2520*1000*1250 | YDSD88E3&S3&SS3 Technical Data.pdf |
| YDSD100E3/S3/SS3 | 90 | 72 | 100 | 80 | 4ZTAA4.1-G22 | E | Y224F | 2520*1000*1250 | YDSD100E3&S3&SS3 Technical Data.pdf |
| YDSD126E3/S3 | 113 | 90 | 125 | 100 | 4HTAA4.3-G21 | E | Y274CS | 2660*1100*1520 | YDSD126E3&S3 Technical Data.pdf |
| YDSD140E3/S3 | 125 | 100 | 140 | 112 | 4HTAA4.3-G23 | E | Y274D | 2660*1100*1520 | YDSD140E3&S3 Technical Data.pdf |
| YDSD165E3/S3 | 150 | 120 | 165 | 132 | 6HTAA6.5-G21 | E | Y274DS | 3150*1100*1750 | YDSD165E3&S3 Technical Data.pdf |
| YDSD180E3/S3 | 160 | 128 | 175 | 140 | 6HTAA6.5-G22 | E | Y274E | 3250*1100*1750 | YDSD180E3&S3 Technical Data.pdf |
| YDSD220E3/S3 | 200 | 160 | 220 | 176 | 6HTAA6.5-G23 | E | Y274G | 3250*1100*1750 | YDSD220E3&S3 Technical Data.pdf |
| YDSD250E3/S3 | 225 | 180 | 250 | 200 | 6DTAA8.9-G21 | E | Y274G | 3650*1220*1950 | YDSD250E3&S3 Technical Data.pdf |
| YDSD275E3/S3 | 250 | 200 | 275 | 220 | 6DTAA8.9-G24 | E | Y274J | 3650*1220*1950 | YDSD275E3&S3 Technical Data.pdf |
| YDSD313E3/S3 | 275 | 220 | 313 | 250 | 6DTAA8.9-G23 | E | Y274J | 3650*1280*1950 | YDSD313E3&S3 Technical Data.pdf |
| YDSD375E3/S3 | 350 | 280 | 375 | 300 | 6ETAA11.8-G22 | E | Y4D | 4210*1500*2200 | YDSD375E3&S3 Technical Data.pdf |
| YDSD437E3/S3 | 400 | 320 | 437 | 350 | 6ETAA12.8-G22 | E | Y4FS | 4310*1700*2200 | YDSD437E3&S3 Technical Data.pdf |
| YDSD500E3/S3 | 450 | 360 | 500 | 400 | 6ETAA12.8-G32 | CR | Y4F | 4310*1700*2200 | YDSD500E3&S3 Technical Data.pdf |
| YDSD550E3/S3 | 500 | 400 | 550 | 440 | 6ETAA12.8-G310.1 | CR | Y5C | 4310*1700*2200 | YDSD550E3&S3 Technical Data.pdf |
| YDSD619E3/S3 | 563 | 450 | 619 | 495 | 6KTAA25-G311 | EUP | Y5D | 5550*1950*2500 | YDSD619E3&S3 Technical Data.pdf |
| YDSD688E3/S3 | 625 | 500 | 688 | 550 | 6KTAA25-G310 | EUP | Y5ES | 5550*1950*2500 | YDSD688E3&S3 Technical Data.pdf |
| YDSD770E3/S3 | 700 | 560 | 770 | 616 | 6KTAA25-G39 | EUP | Y5E | 5700*2050*2540 | YDSD770E3&S3 Technical Data.pdf |
| YDSD825E3/S3 | 750 | 600 | 825 | 660 | 6KTAA25-G32.1 | CR | Y5FS | 5700*2050*2540 | YDSD825E3&S3 Technical Data.pdf |
| YDSD908E3/S3 | 825 | 660 | 908 | 726 | 6KTAA25-G31.1 | CR | Y6B | 5700*2050*2540 | YDSD908E3&S3 Technical Data.pdf |
| YDSD990E3/S3 | 900 | 720 | 990 | 792 | 6KTAA25-G320.1 | CR | Y6C | 5900*2250*2550 | YDSD990E3&S3 Technical Data.pdf |
| YDSD1100E3/S3 | 1000 | 800 | 1100 | 880 | 6KTAA25-G321.1 | CR | Y6D | 5900*2250*2550 | YDSD1100E3&S3 Technical Data.pdf |
